Vibrating Grader
Size grading machine for sizing and sorting of products by vibration
The vibrating grader is designed for the precise sorting and sizing of bulk materials based on their particle size. With multiple layers of sieving, our vibrating graders offer flexible and accurate screening, making them ideal for industries such as mining, construction, chemical processing, and energy. Its powerful vibration mechanism ensures that materials are separated consistently and efficiently, classifying products into different size ranges to meet various industrial demands. The vibrating grader can carry out material separation, contributing to smoother and more efficient production processes.
Specifications
| Model | Screening area (m²) | Production capacity (t/h) | Motor power (kW) | Vibration frequency (r/min) | Amplitude (mm) |
| 3 | 3-5 | 2*1.1 | 960 | 4-6 | |
| 4.8 | 5-10 | 2*1.1 | |||
| 7 | 10-15 | 2*1.5 | |||
| 7.5 | 15-20 | 2*1.85 | |||
| 9.6 | 20-25 | 2*2.2 | |||
| 10 | 25-30 | 2*2.2 | |||
| 12 | 30-35 | 3*2 | |||
| 13.2 | 35-40 | 3*2 |
Features
- The vibrating force applied to the sieve not only efficiently separates raw fertilizer materials but also helps clear any residue stuck within the mesh holes.
- Equipped with fan-shaped eccentric blocks as the excitation source, the grading machine delivers strong and consistent vibrational energy for efficient sorting.
- The sieve beams and box are connected using high-strength bolts, ensuring a simple structure and making maintenance quick and easy.
- Designed with small amplitude, high frequency, and large inclination, the vibrating grader offers high screening efficiency, large processing capacity, extended service life, and operates with low energy consumption and noise.
